AT5832
$0.00
12W LED Polycarbonate bulkhead – IP65 with wall washer option included.
- 12W LED Polycarbonate bulkhead – IP65 with wall washer option included.
- Wall washer option included
- Low glare polycarbonate opal diffuser
- Stylish Design
- Ideal for Residential, commercial, and decorative
Specifications
Efficiencies
| Total System Efficiency | |
|---|---|
| AT5832/BLK | 80 lm/W |
| AT5832/WH | 82 lm/W |
| The performance of each component of a luminaire is demonstrated through its efficiencies, which together determine the total system efficiency of the product. The output of the LED chip is first multiplied by the optical and thermal efficiencies to calculate the Luminaire efficiency. However, this calculation does not consider the driver efficiency. To determine the overall efficiency of the system, the Luminaire efficiency must be multiplied by the driver efficiency, which accounts for all losses in the system. | |
Mechanical
| IP Rating | IP65 |
|---|---|
| IC Rating | Non-IC |
| Adjustability | Fixed |
| Fitting Colour | |
| AT5832/BLK | Black |
| AT5832/WH | White |
| Product Finish | Plastic |
| Body Material | Polycarbonate |
| Diffuser Material | Polycarbonate |
| Installation Type | Surface mount |
Electrical
| Working Temp Range | -20 to 40 °C |
|---|---|
| Input Frequency | 50 Hz |
| Switch Type | Inline |
| Power Factor | 0.9 |
| Maximum Wattage | 12 W |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
Lamp
| Colour Rendering Index (CRI) | >80 |
|---|---|
| Number of Lamps | 1 |
| CCT Configuration | Single |
| Macadam Steps (SDCM) | 6-step MacAdam Ellipse |
| Beam Angle | 120 ° |
| Lamp/LED voltage | 78 V |
| Lamp/LED Current | 47 mA |
LED Lifetime
| LED Lifetime | 30000 hrs |
|---|---|
| This is the Reported LED Lifetime in Hours based on TM-21. Atom does not list the projected or calculated LED lifetime, which is normally longer as TM-21 Addendum B explicitly states "The Calculated and Projected Lp(Dk) are not to be reported". This Lifetime refers to the life of a single LED however the system life is longer since the probability and binomial distribution of all LEDs in the system means that the average led is performing above the specification and compensates for the LEDs falling below. | |
Colour temperature
| CCT Colour | Cool White |
|---|---|
| LED Wattage | 10.9 W |
| Luminaire Lumens | |
| AT5832/BLK | 960 lm |
| AT5832/WH | 980 lm |
| All photometric data has a tolerance of ±10%. Luminaire lumens refers to the exit lumens or delivered lumens from the luminaire. | |
| CCT | 4000 K |
Driver
| Driver Type | Fixed output |
|---|---|
| Driver Included | Yes |
| Integrated Driver | No |
| Dimmable | No |
| Wiring Type | Re-wireable terminal block (3 pin) |
| Driver Mode | Constant Current |
| Driver Current | 140 mA |
Compliance
| Standards |
|
|---|
Warranty
| VIP Warranty | 2 Onsite, 3 RTB (Total 5 Years) |
|---|---|
| VIP warranty is available to registered users and is subjected to additional terms and conditions. Register as a VIP today. Our standard warranty is return-to-base. Onsite warranty is only available to users who are registered, for sites located in the defined areas/regions and for purchases that have been registered. | |
| Domestic Use Warranty | 3 RTB (Total 3 Years) |
Dimensions
| Product Height | 70 mm |
|---|---|
| Product Length | 230 mm |
| Product Width | 105 mm |
Ordering Information
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 10269 | AT5832/BLK | 12W LED Rectangle polycarbonate bulkhead - IP65 wall washer option - Black - Cool White | |
| 10419 | AT5832/WH | 12W LED Rectangle polycarbonate bulkhead - IP65 w/wall washer option - White - Cool White |
