AT3013 SLIM
$0.00
Slim opal acrylic LED oyster tri-colour
- Versatile surface-mount design with slim 70mm profile
- Provides energy-efficient illumination as low as 94lm/W
- Tri-CCT selectable, allowing for customisation of colour temperature to suit the application
- Easy to install and maintain
- Insect-resistant seal helps to maintain cleanliness of the fitting
- IP44 rated, making it suitable for kitchens, bathrooms and laundries
Selected Models
- In-built motion sensor turns off light when not in use for optimal energy efficiency
Specifications
Efficiencies
| Total System Efficiency | |
|---|---|
| AT3013/SLIM/25/TRI/S | 94 lm/W |
| AT3013/SLIM/14/TRI | 96 lm/W |
| AT3013/SLIM/25/TRI | 100 lm/W |
| AT3013/SLIM/17/TRI | 109 lm/W |
| The performance of each component of a luminaire is demonstrated through its efficiencies, which together determine the total system efficiency of the product. The output of the LED chip is first multiplied by the optical and thermal efficiencies to calculate the Luminaire efficiency. However, this calculation does not consider the driver efficiency. To determine the overall efficiency of the system, the Luminaire efficiency must be multiplied by the driver efficiency, which accounts for all losses in the system. | |
Mechanical
| Body Material | Steel |
|---|---|
| Diffuser Material | Acrylic |
| Fitting Colour | White |
| Installation Type | Wall or Ceiling |
| IP Rating | IP44 |
Electrical
| Electrical Rating | Class I |
|---|---|
| Input Current | 0.07 A |
| Input Frequency | 50 Hz |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
| Maximum Wattage | |
| AT3013/SLIM/14/TRI | 14 W |
| AT3013/SLIM/17/TRI | 17 W |
| AT3013/SLIM/25/TRI AT3013/SLIM/25/TRI/S | 25 W |
| Power Factor | 0.95 |
| Switch Type | Inline |
| Working Temp Range | -20 to 40 °C |
Lamp
| CCT Configuration | TRI-CCT |
|---|---|
| Colour Rendering Index (CRI) | >80 |
LED Lifetime
| LED Lifetime | >54,000 hrs | ||||||
|---|---|---|---|---|---|---|---|
| This is the Reported LED Lifetime in Hours based on TM-21. Atom does not list the projected or calculated LED lifetime, which is normally longer as TM-21 Addendum B explicitly states "The Calculated and Projected Lp(Dk) are not to be reported". This Lifetime refers to the life of a single LED however the system life is longer since the probability and binomial distribution of all LEDs in the system means that the average led is performing above the specification and compensates for the LEDs falling below. | |||||||
| LED Lifetime Ratings (Failure rate & lumen depreciation) | |||||||
AT3013/SLIM/14/TRI AT3013/SLIM/17/TRI |
| ||||||
AT3013/SLIM/25/TRI |
| ||||||
| This rating defines the performance of the led within its lifetime. L relates to lumen depreciation, where the proceeding number gives the resultant lumen output at the end of it reported lifetime. L70, would mean 30% lumen depreciation which means 70% of its initial output and is tested accordingly to TM-21. The B part refers to failures, which can be define as the percentage of LEDs which fall below the L value in the projected lifetime. A value of B10 refers to 10% failure and a value of B50 refers to 50% failure. After the defined lifetime, the system will reach the defined lumen depreciation and the average led failures is defined by the B rating. The B rating is defined in and tested to IEC62717. | |||||||
| TM-21 Test Hours | 9000 hrs | ||||||
Colour temperature
AT3013/SLIM/14/TRI
| |||||||||||
AT3013/SLIM/17/TRI
| |||||||||||
AT3013/SLIM/25/TRI
| |||||||||||
AT3013/SLIM/25/TRI/S
| |||||||||||
Driver
| Dimmable | No |
|---|---|
| Driver Included | Yes |
| Driver Mode | Constant Current |
| Driver Type | Fixed output |
| Wiring Type | Re-wireable terminal block (3 pin) |
Sensor (S suffix)
| Adjustable Detection Area / Sensitivity | Yes |
|---|---|
| Adjustable Hold Time | Yes |
| Adjustable Standby Level | Yes |
| Adjustable Standby Period | Yes |
| Corridor Function | Yes |
| Detection Range | 8 m |
| Dusk Mode | Yes |
| Lux Adjustment | Yes |
| Lux Range | 2/10/50/- lx |
| Sensor Type | Microwave |
| Switched Output | No |
| Time Delay | 5s/0.5/1/5 |
Energy Savings Scheme
| Ipart Approval | Yes |
|---|---|
| REES Approval | Yes |
| VEU Approval | Yes |
Compliance
| Standards |
|
|---|
Warranty
| Domestic Use Warranty | 3 RTB (Total 3 Years) |
|---|---|
| VIP Warranty | |
| AT3013/SLIM/25/TRI/S | 2 Onsite, 3 RTB (Total 5 Years) |
| AT3013/SLIM/14/TRI AT3013/SLIM/17/TRI AT3013/SLIM/25/TRI | 3 Onsite, 2 RTB (Total 5 Years) |
| VIP warranty is available to registered users and is subjected to additional terms and conditions. Register as a VIP today. Our standard warranty is return-to-base. Onsite warranty is only available to users who are registered, for sites located in the defined areas/regions and for purchases that have been registered. | |
| Domestic Use Warranty | 3 (Yr) RTB |
Dimensions
| Item Code | Product Diameter | Product Height |
|---|---|---|
| AT3013/SLIM/14/TRI | 300 mm | 70 mm |
| AT3013/SLIM/17/TRI | 350 mm | 70 mm |
| AT3013/SLIM/25/TRI | 400 mm | 70 mm |
| AT3013/SLIM/25/TRI/S | 400 mm | 70 mm |
AT3013/SLIM/14/TRI
AT3013/SLIM/17/TRI
AT3013/SLIM/25/TRI
Ordering Information
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 18270 | AT3013/SLIM/14/TRI | SLIM 14W 300mm Dia Oyster - Tri CCT | |
| 18271 | AT3013/SLIM/17/TRI | SLIM 17W 350mm Dia Oyster - Tri CCT | |
| 18272 | AT3013/SLIM/25/TRI | SLIM 25W 400mm Dia Oyster - Tri CCT | |
| 18138 | AT3013/SLIM/25/TRI/S | SLIM 25W 400mm Dia Oyster - Tri CCT - With Sensor |
