Efficiencies

Total System Efficiency

115 lm/W

The performance of each component of a luminaire is demonstrated through its efficiencies, which together determine the total system efficiency of the product. The output of the LED chip is first multiplied by the optical and thermal efficiencies to calculate the Luminaire efficiency. However, this calculation does not consider the driver efficiency. To determine the overall efficiency of the system, the Luminaire efficiency must be multiplied by the driver efficiency, which accounts for all losses in the system.

Mechanical

IP Rating	IP54 Front Face Only
IC Rating	IC-4
IC-4 rating has been conducted at the products maximum working Temperature Range (C) in line with Australian standards. This provides the required safety when covered with insulation and used in Australian Environments.
Adjustability	Fixed
Fitting Colour	White
Product Finish	Powdercoated
Body Material	Aluminium
Diffuser Material	PMMA
Installation Type	Recessed

Electrical

Working Temp Range	-20 to 40 °C
Input Frequency	50 Hz
Switch Type	Inline
Maximum Wattage	10 W
System Max Wattage	10 W
Input voltage	230Vac
In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%

Lamp

Colour Rendering Index (CRI)	>80
CCT Configuration	TRI-CCT
Macadam Steps (SDCM)	5-step MacAdam Ellipse
Beam Angle	90 °
Lamp/LED voltage	36 V
Lamp/LED Current	230 mA

LED Lifetime

LED Lifetime	>54,000 hrs
This is the Reported LED Lifetime in Hours based on TM-21. Atom does not list the projected or calculated LED lifetime, which is normally longer as TM-21 Addendum B explicitly states "The Calculated and Projected Lp(Dk) are not to be reported". This Lifetime refers to the life of a single LED however the system life is longer since the probability and binomial distribution of all LEDs in the system means that the average led is performing above the specification and compensates for the LEDs falling below.
TM-21 Test Hours	9000 hrs

Colour temperature

Warm White (3000 K)	1050 lm
Cool White (4000 K)	1150 lm
DayLight (5700 K)	1100 lm

Driver

Driver Type	Dimmable ( Phase cut)
Driver Included	Yes
Integrated Driver	No
Dimmable	Yes
Flex & Plug or Lead Length	600 mm
Wiring Type	Re-wireable Flex & Plug (2 pin)
Driver Mode	Constant Current
Driver Current	230 mA

Compliance

Standards	AS/NZS 60598.1 AS/NZS 60598.2.2 AS/NZS 61347.1 AS/NZS 61347.2.13 AS CISPR 15

Warranty

Warranty	5 Year Warranty, First 2 Years Onsite
The total warranty period is shown above. Where an on-site period is listed, the first years are covered on-site, with return-to-base coverage for the remainder. For full warranty details and claim instructions, please refer to our Warranty page.

Dimensions
