Mooloolah

$0.00

6 blade 55W DC ceiling fan

  • Our most powerful and energy efficient 55W DC motor
  • Easy installation with our quick connect wiring solution
  • Pre-balanced for smoother, quieter operation
  • Suitable for indoor and covered outdoor applications
  • Fitted with 8 corrosion-resistant anodised aluminium blades
  • Hangsure canopy up to 15 degrees
  • Reversible for summer and winter use (via remote control)
  • Supplied with 8 speed remote with turbo speed function and up to 12h timer
SKU: Mooloolah Category: Tag:
Specifications

Mechanical

Body MaterialMetal
Fitting ColourMatt Black
IP RatingIP20

Electrical

Electrical RatingClass I
Input Frequency50 Hz
Input voltage230Vac
In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6%
Working Temp Range-10 to 40 °C

Air Movement

Motor Wattage55 W
Motor TypeDC
No. Speeds8
ControlRemote control
Ceiling Rake15 °
Ceiling Drop270 mm
Blade Pitch11 °
Blade MaterialAluminium
Fan Size2130mm (84inch)
Fan Speed 113 W, 54 rpm, 13200 m³/h
Fan Speed 219 W, 59 rpm, 14100 m³/h
Fan Speed 325 W, 64 rpm, 1500 m³/h
Fan Speed 431 W, 69 rpm, 15900 m³/h
Fan Speed 537 W, 74 rpm, 16800 m³/h
Fan Speed 643 W, 79 rpm, 17500 m³/h
Fan Speed 749 W, 84 rpm, 18300 m³/h
Fan Speed 855 W, 90 rpm, 19500 m³/h

Compliance

Standards
  • AS/NZS 60335.1
  • AS/NZS 60335.2.80
  • AS/NZS CISPR 14
  • AS/NZS 4268

Warranty

Domestic Use Warranty4 Onsite, 2 RTB (Total 6 years)
Dimensions
Product Height303 mm
Product Weight8450 g
Product Width2130 mm
MOOLOOLAH/84
Ordering Information
Order codeItem codeDescriptionAvailability
18487MOOLOOLAH/84/BK84 inch (2130mm) 6 blade 55W DC ceiling fan black
Documents & Downloads

Instruction Manual


*Auto generated datasheet (beta)
Accessories
Order codeItem codeDescriptionAvailability
12508DCREMOTE/BKRemote control for DC ceiling fans - Remote only - Black
12514ROD/150/BK1500mm Extension rod for ceiling fans w/loom - Black
12512ROD/90/BK900mm Extension rod for ceiling fans w/loom - Black
