AT9261
$0.00
4-Channel Amplifier/Repeater for LED Strip
- Works with all 12/24Vdc PWM controlled LED strip
- Connect 1 or more amplifiers to create even longer LED strips
- High performance switching frequency 10Mbps
- 6A per channel
- 15A total max output
Specifications
Mechanical
| IP Rating | IP20 |
|---|---|
| Fitting Colour | White |
| Body Material | Polycarbonate |
Electrical
| Working Temp Range | -20 to 60 °C |
|---|---|
| Input voltage | DC 12/24 |
Driver
| Dimmable | Yes |
|---|---|
| Wiring Type | Re-wireable terminal block (6 pin) |
| Driver Mode | Constant Voltage |
| Driver Current | 6000 per channel mA |
Compliance
| Standards |
|
|---|
Warranty
| Domestic Use Warranty | 3 RTB (Total 3 Years) |
|---|
Dimensions
| Product Height | 23 mm |
|---|---|
| Product Length | 119 mm |
| Product Width | 47 mm |
Ordering Information
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 16648 | AT9261/RGB | 4-Channel Amplifier/Repeater for LED Strip |
Documents & Downloads
*Auto generated datasheet (beta)
