Specifications
Mechanical
| IP Rating | IP20 |
|---|---|
| Body Material | Polycarbonate |
Electrical
| Working Temp Range | 0 to 45 °C |
|---|---|
| Input Frequency | 50 Hz |
| Input voltage | 200-240Vac |
Driver
| Driver Type | Dimmable ( Phase cut) |
|---|---|
| Dimmable | Yes |
| Flex & Plug or Lead Length | 900 mm |
| Wiring Type | Re-wireable Flex & Plug (2 pin) |
| Driver Mode | Constant Current |
| Driver Power | |
| AT9665 | 18 W |
| AT9666 | 24 W |
| AT9668 | 32 W |
| Driver Current | |
| AT9665 | 450 mA |
| AT9666 | 600 mA |
| AT9668 | 800 mA |
| Output Voltage Range | 30-40 V |
| PSTLM | |
| AT9665 | 0.008 |
| AT9666 | 0.01 |
| Short Term Light Modulation (PstLM): The requirement is that PstLM should be less than or equal to 1.0. This metric measures the short-term flicker severity and ensures that flicker is not perceptible or is at a level that does not cause discomfort or health issues. | |
| SVM | |
| AT9666 | 0.001 |
| AT9665 | 0.004 |
| Stroboscopic Visibility Measure (SVM): The requirement for SVM is that it should be less than or equal to 0.4. The SVM metric assesses the visibility of the stroboscopic effect, which can make moving objects appear to be stationary or moving in discrete steps, thus ensuring that this effect is minimized in lighting environments to prevent visual discomfort and safety hazards. | |
Compliance
| Standards |
|
|---|
Ordering Information
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 11572 | AT9665 | 16W Phase Dimmable Driver 450mA to suit 306 Backlit Panels - AT6023 SER III | |
| 11573 | AT9666 | 25W Phase Dimmable Driver 600mA to suit 606 and 312 Backlit Panels - AT6023 SER III | |
| 15004 | AT9668 | DRIVER KIT - 32W Phase Dimmable Driver 800mA - 30-40V DC - with Flex and plug and output cable |
Documents & Downloads
*Auto generated datasheet (beta)
