Buffalo
$0.00
High velocity 3-in-1 bathroom heater
- Super-efficient 40W ball bearing motor for superior reliability
- Quality tri-CCT colour selectable LED panel provides efficient illumination
- Infrared heat lamps provide instant heat
- 3-year in-home warranty for peace of mind
- Includes integrated draught stopper, wall switches, 1.5m duct and grill outlet
- Ideal for larger sized bathrooms
Selected Models
- Built in thermostat switch turns fan on automatically if temperature exceeds 80°C
- Built in 80°C thermal cutout switch for added safety
Specifications
Mechanical
| Product Finish | Matt |
|---|---|
| Fitting Colour | White |
| IC Rating | Do not cover |
| Installation Type | Recessed |
| IP Rating | IPx4 |
Electrical
| Electrical Rating | Class I |
|---|---|
| Input Frequency | 50 Hz |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
| Working Temp Range | -10 to 40 °C |
Lamp
| CCT Configuration | TRI-CCT |
|---|---|
| Colour Rendering Index (CRI) | >80 |
Colour temperature
BUFFALO/2LT/WH
| |||||||||||
BUFFALO/4LT/WH
| |||||||||||
Air Movement
| Outlet | 150 mm |
|---|---|
| Noise level | 45 dB |
| Motor Wattage | 40 W |
| Motor Type | Ball bearing |
| Fan Type | Centrifugal |
| Air extraction | 400 m3/hr |
Heat
| Heater Type | |
|---|---|
| BUFFALO/2LT/WH | 2x 275W IR Heat Lamp (E27) |
| BUFFALO/4LT/WH | 4x 275W IR Heat Lamp (E27) |
Compliance
| Product Design Life | 10 years |
|---|---|
| The product design life relates to the total product life which includes LEDs, drivers and the enclosure. This is different to the LED lifetime which only refers to the economical lifetime of the LEDs at which time the lumen output has dropped below the L Value. The product design life is calculated at the maximum ambient or working temperature of the product and takes into account the Daily Use. | |
| Daily Use | 2 hrs |
| The Daily Use is the recommended time required to meet the product's design life. Installations can exceed this time, however the product design life will be reduced proportionally. | |
| Standards |
|
Warranty
| Domestic Use Warranty | 3 Onsite (Total 3 Years) |
|---|---|
| Warranty Operating Hours | 2500 hrs |
| This product is provided with a warranty up until the stated warranty period or until the stated warranty operating hours has been reached (whichever occurs first). | |
Dimensions
| Item Code | Minimum Ceiling Depth | Cutout | Product Height | Product Length | Product Width |
|---|---|---|---|---|---|
| BUFFALO/2LT/WH | 250 mm | 465x245 mm | 197 mm | 524 mm | 305 mm |
| BUFFALO/4LT/WH | 250 mm | 375x375 mm | 193 mm | 450 mm | 450 mm |
BUFFALO/2LT/WH
BUFFALO/4LT/WH
Ordering Information
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 16771 | BUFFALO/2LT/WH | 2-Light high-velocity bathroom heater & exhaust w/LED panel - white - Tri-cct | |
| 16772 | BUFFALO/4LT/WH | 4-Light high-velocity bathroom heater & exhaust w/LED panel - white - Tri-cct |
Documents & Downloads
Datasheet
*Auto generated datasheet (beta)
Accessories
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 18716 | AT9709/ES/HEAT/275 | 275W R125 INFRARED HEAT LAMP E27 |
